STYKAČ LT1 D9511 12V 1NO+1NC Bestseller

Technical characteristics:
– Rated current: 9-225А
– Rated operating voltage of the controlling coil: 12V DC to 220V DC
– Rated operating voltage of the power circuit: up to 690V DС
– Insulation voltage: 690V
– Surge voltage wear resistance: >8000V
– Electrical wear resistance (number of cycles): ≥10000000
– Mechanical wear resistance (number of cycles): ≥10000000
– Number of cycles per hour: 1200pcs up to 32А; 600pcs for 40-95А
– Ambient temperature: -10° to 65ºС
– Maximum altitude: up to 2000m
